Features
These ignition protected battery switches are designed for inboard and diesel engines. The cases feature luminous face plate and pointer and an easy-grip knob, and allow surface or rear panel mounting. The one-piece terminal stud design never loosens over time. 3/8"-16 tin-plated copper studs offer maximum conductivity and corrosion-resistance. 7/8" stud length accepts 3/8" and M10 ring terminals. Mounting holes accept 1/4" screws and fit most PERKO and Guest battery switch hole patterns. Devices meet ABYC requirements and UL and SAE external ignition protection requirements, are UL-listed, and are waterproof rated to IP66. 3.85"H x 3.85"W x 3.097"D.
Dual Circuit Battery Switch (5510e) - Simultaneously switches two isolated battery banks. 2 switch positions (ON-OFF). 2 battery inputs.
Continuous Rating: 350 Amps
Intermittent Rating (5 min.): 600 Amps
Cranking Rating @ 10 sec: 2000 Amps
Cranking Rating @ 1 min: 1000 Amps
Terminal Stud Torque: 140 in-lb maximum
Cable Size (to meet requirements): 4/0 AWG
Cable Clearance: 1.1"
Show moreShow less
Dual Circuit Battery Switch (5510e) - Simultaneously switches two isolated battery banks. 2 switch positions (ON-OFF). 2 battery inputs.
Continuous Rating: 350 Amps
Intermittent Rating (5 min.): 600 Amps
Cranking Rating @ 10 sec: 2000 Amps
Cranking Rating @ 1 min: 1000 Amps
Terminal Stud Torque: 140 in-lb maximum
Cable Size (to meet requirements): 4/0 AWG
Cable Clearance: 1.1"
- For inbord and diesel engines
- Easy grip knob has luminous face plate and pointer
- Ignition protected
- One-piece terminal stud design never loosens
- Available in Selector or Single Circuit models
Specs
Unit Weight | 1.14 lb |
---|---|
Brand | Blue Sea Systems |
